20
Charger functions
This charger is suitable for Li-ion batteries.
The LED (LED 1) on the charger keeps you
constantly informed of the operating status.
You will be informed about the status and
charging of the battery at a glance.
Disorders
Please check:
- Is the power cable connected correctly?
- Are the contacts of the charger and the
battery clean and not damaged or bent?
- Is the battery damaged or defective?
If proper battery charging is not possible:
- Check whether the socket carries voltage,
if necessary connect it to other consumers.
- Check for perfect contact with the
connectors.
- If charging is still not possible, please have
the battery and charger checked by the
dealer.
charging cycle and LED indicators for lithium-ion battery
LED Model
Green Battery not yet connected
Red Charging process / electricity is flowing
Green Charging finished / no current is flowing
