PARTS LIST continued
Page 4 SET 5303
Item No. Function/Rating Mfr. Part No. Notes
Item No. Function/Rating Mfr. Part No. Notes
Important Parts Information
n Parts not listed in the parts list are commonly available at your local electronics parts retailer.
n The parts listed here are those not usually available from a well-stocked supply cabinet or bin.
n On the parts lists, safety items are marked with a # to remind you that only exact replacements are recommended for
these items.
n When ordering parts, state the model number, part number, and description.
Obtaining Parts
Many of these parts are available from your local Sams authorized distributor or the manufacturer of the equipment. Call
Sams for the name of your nearest distributor:
800-428-7267
P905 Jack 268360 Assembly
R302 3900 1% 1/4W 268381 -
R303 36K 1% 1/4W 268429 -
33K 1% 1/4W 268382 -
R311 10K 1% 1/4W 268385 -
R312 18K 1% 1/4W 268386 -
R404 4700 5% 7W 268390 -
# R516, 17, 18 15K 2W - -
4700 5% 1/6W 266282 -
# R801 1M 20% 1/2W 266940 -
R820 Fuse 268410 5Amp, 250VAC
R821, 23 Fuse 268411 3Amp, 250VAC
R827 4700 5% 5W 268413 -
R834A 6800 1% 1/4W 176634 -
R834B 390 1% 1/4W 266595 -
R835 120K 1% 1/2W 268414 -
# R840 8.2M 1W 266941 -
# RL01 Relay 268417 Degaussing
# RT801 (1)(6) PTC 268418 -
# RT801 (2)(3)(4)(5) PTC 270926 -
# RT802 NTC 266357 -
S002A Switch 267136 Menu
S003A Switch 267136 Volume -
S004A Switch 267136 Volume +
S005A Switch 267136 Channel -
S006A Switch 267136 Channel +
S008 Switch 267136 Power
# S501 Socket 266290 CRT
# T401 Horizontal Drive 266291 -
# T402 (7) Horizontal Output 268419 -
# T801, 02 Line Filter 268420 -
# T803 Power 268421 -
TU101 Tuner 270388 TEDH9-251A
# V801 CRT - -
VR802 330 B+ 270389 -
2000 B+ - -
W601, 02 (1) Speaker 270373 16 Ohms, 8W
W601, 02 (6) Speaker 268472 16 Ohms, 5W
W601, 02 (2)(3)(4)(5) Speaker 271001 60mm X 125mm, 16 Ohms
X001 Crystal 266315 8MHz
X201 Trap 266318 4.5MHz
X202 Filter 266317 4.5MHz
X1001 Crystal 268423 18.432MHz
Z101 Filter 266319 SAW
PC Board (4) 270963 Comb Filter
PC Board (2)(5) 270959 CRT
PC Board (3)(4) 270964 CRT
PC Board (2)(3)(4)(5) 270958 IR Receiver
PC Board (2)(3)(4)(5) 270961 Keyboard
PC Board (2)(3)(4)(5) 270962 Side
PC Board (3)(5) 260967 Yoke Adapter
Spacers 267049 Yoke Positioning (3 Used)
Transmitter (2)(3)(4)(5) 265714 Remote, RCR130TB1
Transmitter (1)(6) 270372 Remote
# For SAFETY use only equivalent replacement part.
(1) Used in model 27V412T.
(2) Used in model 27V412TYX1.
(3) Used in model 27V412TYX3.
(4) Used in model 27V412TYX5.
(5) Used in model 27V412TYX8.
(6) Used in model 24V412T.
(7) Screen and focus controls are part of T402.
