RCA ANT1250 User Manual

6
Tuning and Adjustments
Take the following steps to tune and adjust your antenna.
1. Select the channel you want to watch.
2. Turn the antenna power on by switching the 3 position switch to
the appropriate position.
3. Move the extended dipoles (channels 2-13) or the loop
(channels 14 and higher) until you get the best picture possible.
4. Increase the antenna power by turning the UHF or VHF Power
Control Dial clockwise until you get the best picture possible.
5. This process may need to be repeated each time channels
are changed.
MIN
M
A
X
V
H
F
M
I
N
M
A
X
U
H
F
UHF & VHF Power Control Dial
VHF Dipole
UHF Loop & Reflector
MIN
MIN
M
A
X
U
H
F
3 Position Switch
VHF Dipole
ANT1250_IB 7/19/01 9:12 AM Page 6
