5
ENGLISH
1. If you’re using the provided coaxial cable, thread it through
one of the U-bolts.
Find the coaxial cable and one of the U-bolts
included in this package. Thread the coaxial cable
through the U-bolt as shown here.
IMPORTANT: If you’re not using the coaxial cable that came with this
antenna, skip step 1.
4. Connect the coaxial cable to the antenna.
Connect the coaxial cable to the F-connector on the bottom of the
antenna. Cover the connector with the cable’s attached weather boot.
To adjust the antenna’s position:
1. Loosen the bolt on either end of the arm.
2. Move the arm or antenna to the desired position.
3. Re-tighten the bolt so that the antenna and arm stay fi rmly in
position.
continues on next page...
Mounting to a Mast
