RCA CC6364/CC6374

Other Information
84 Chapter 6
Specifications
Camcorder
Format
VHS NTSC standard
Power source
DC 11 V (Using AC power
supply)
DC 6 V
(Using battery pack)
Power consumption
Viewfinder on:
4.0 W (CC6364)
4.5 W (CC6374)
LCD monitor on:
5.2 W (CC6364)
5.4 W (CC6374)
Video light: 3.0 W
Signal system
NTSC-type
Video recording system
Luminance: FM recording
Color: Converted sub-carrier direct
recording conforms to VHS standard
Cassette tape
VHS-C cassette tape
Tape speed
SP: 33.35 mm/sec. (1-5/16 ips)
SLP: 11.12 mm/sec. (7/16 ips)
Recording time (max.)
SP: 40 minutes
SLP: 120 minutes (with TC-40)
Operating temperature
0°C to 40°C (32°F to 104°F)
Operating humidity
35% to 80%
Storage temperature
–20°C to 50°C (–4°F to 122°F)
Weight
Approx. 900 g (2.0 lbs)
Specifications
Dimensions (W x H x D)
206 mm x 112 mm x 118 mm (8-1/8" x 4-7/16"
x 4-11/16") (with the LCD monitor closed and
with the viewfinder fully tilted downward)
Pickup
1/4" format CCD
Lens
F1.6, f = 3.9 mm to 62.4 mm, 16:1 power
zoom lens with auto iris and macro control,
filter diameter 40.5 mm
Viewfinder
Electronic viewfinder with .5” black and white
CRT.
White balance adjustment
Auto/Manual adjustment
LCD monitor system
2.5" diagonally measured, LCD panel/TFT
active matrix
Speaker
Monaural
Audio/Video Jacks
Video
1 V (p-p), 75 Ω unbalanced, analog output
(via Video output connector)
Audio
300 mV (rms), 1 kΩ analog output (via Audio
output connector)
AC Power Supply
Power requirement
U.S.A. and Canada: AC 120 V, 60 Hz
Other countries: AC 110 V to 240 V‘, 50 Hz/60
Hz
Output
DC 11 V , 1 A
Dimensions (W x H x D)
59 mm x 31 mm x 69 mm (2-3/8" x 1-1/4" x 2-
3/4")
Weight
Approx. 130 g (0.29 lbs)
