4
First-Time Operation
2. Adjust the handstrap to fit your hand.
A. Lift the flap on the handstrap
and separate the Velcro strip.
B. Insert your hand so your
fingers can comfortably reach
the camera buttons.
C. Adjust the strap to fit snugly.
D. Refasten the strap, and fold
the flap back down.
Handstrap
Handstrap
Velcro Strip
(Under Flap)
3. Attach the adapter/charger.
Since the battery must be charged before it can be
used the first time, attach the adapter/charger to the
camcorder using the included DC power cable.
C. Plug the adapter/charger’s
plug into a working power
outlet.
A. Connect one end of the DC
cable to the DC OUT jack on
the adapter/charger.
B. Connect the other end of the
DC cable to the DC in jack on
the camcorder.
DC In jack
DC cable
Adapter/charger
model 247801
To AC outlet
100-240, 50/60 Hz
DC OUT jack
To Next Page
