TOUR OF THE DOORBELL CAMERA
FRONT BACK
Lens captures video in front of the doorbell.
Micro SD card slot holds the micro SD card
that comes with your doorbell camera.
IR sensor detects changes in ambient light
and adjusts video settings accordingly.
RESET button restores the doorbell camera
to factory settings (hold for 15 seconds).
Call button triggers the doorbell.
Screw terminals
connect to the
doorbell power
source from your
home.
Your doorbell camera comes with an SD card pre-installed, for recording alerts.
To remove or replace this card, you’ll rst need to remove the doorbell camera’s
faceplate by unlocking its set screws and pulling it off. Press the installed SD card
to unlock it and pull it out. Place the new SD card in and lock it into place. Then
place the SD card cover back on and put the doorbell camera’s faceplate over the
doorbell camera. Finally, insert the set screw and screw it back in place.
Removing/Replacing the SD Card
