INSTRUCTION MANUAL
RDR2xx0 Series Professional
Digital Two-Way Radios
PRODUCT INSPECTION
Prior to unpacking the RDR2xx0 series portable radio, please inspect
the packaging for signs of damage and report any damage or missing
components immediately to your RCA Communications System Sales
and Service Center. Every RDR2xx0 series portable radios should
come with the following items:
Item Qty.
RDR2500
TM
/RDR2550
TM
/RDR2600
TM
-Handheld Radio 1
B2618LI - Li-Ion Battery (1800 mAh) 1
ANH3500U-W - Antenna for UHF Models
ANH3500V-W - Antenna for VHF Models
1
BC2600 - Belt Clip 1
CH2601 - Desktop Rapid Charger 1
PS2601 - Power Supply 1
Wrist Strap 1
B2618LI
Li-Ion Battery
(1800 mAh)
CH2601
Desktop Rapid Charger
PS2601
Power Supply
BC2600
Belt Clip
Antenna
ANH3500U-W - UHF models
ANH3500V-W - VHF models
RDR2500
TM
Handheld Radio
RDR2600
TM
Handheld Radio
RDR2550
TM
Handheld Radio
RCA RDR2xx0
TM
Series Overview
RDR2500 RDR2550 RDR2600
RDR2500
RDR2550
RDR2600
1
3
2 4
5
7
6
11
12
15
16
17
18
13
14
8
9
10
1 Antenna 7 Microphone 13
Side Button 2
(Programmable)
2 Top Button (Programmable) 8 Display (RDR2550/RDR2600) 14
Side Button 3
(Programmable)
3 Channel Knob 9 Limited Keypad (RDR2550) 15 Accessory Connector
4 LED Indicator 10 Full Keypad (RDR2600) 16 Screw-On Belt Clip
5 On/O/ Volume Knob 11
Side Button 1
(Programmable)
17 Battery
6 Speaker 12 Push-to-Talk (Programmable) 18
Battery Charging
Contact Points
Note: The frequency
band of your RDR2500™,
RDR2550™, RDR2600™
is marked on the radio
label. If it is not visible,
identify the frequency
band according to the
marking on the antenna:
white indicates UHF
and red indicates VHF.
