Main unit description
Control Panel
Button Function
VOL+
:
Increase volume; if OSD is active, functions as right in the menu;
in SOURCE menu, functions as ENTER.
VOL- :
Decrease volume; if OSD is active, functions as left in the menu.
CH+
:
Change channel up; if OSD is active, functions as up in the menu
CH-
:
MENU : Press to select the main menu.
SOURCE : Select the input signal.
POWER : Switch on when at standby mode or enter the standby mode.
Change channel down; if OSD is active, functions as down in
the menu.
TV
Terminal Connections
1. OPTICAL
out terminal.
4. (Mini) Line out terminal.
3. Video/Y Pb Pr input terminal
5. HDMI1(2.0/4K2K) input terminal.
8. HDMI4(1.4/4K2K,)/MHL input terminal.
6. HDMI2(2.0/4K2K) input terminal.
9. RF antenna.
2. AUDIO input terminal.
10. USB input terminal (only for service).
1 2
3 4 5 6 7 8 9 10
7. HDMI3(1.4/4K2K,) input terminal.
