2. V-BR - VERTICAL BRACKETS
BRACKET FIXED WITH BOLT
BRACKET FIXED WITH KNOB
Tilt the speaker until you match the inclination needed, then screw the M6 bolt or knob (with its washers)
F
on a tilt fixing hole�
F
F
NOTE: These exact same operations must be done on both sides of the speaker
NOTE: once the speaker angle is defined, tighten strongly the M10 knob or bolt
The system is now set and ready to be used�
