13
ENGLISH
4) Reverse and connect the 1 rear bracket to the fly-bar using 2 quick lock pins.
The first HDL has to be fixed always starting at 0° with respect of the frame. No other
angles are allowded.
5) Connect the second cabinet to the first always starting from the 2 front brackets.
6) Reverse and connect the rear bracket of the second cabinet using the hole for the proper
angle.
7) Connect all the other cabinets following the same procedure and connecting a single
cabinet each time.
