EPSILON ES2,ES4
7
Kind of bumper ring
5 holes.
4.5mm
10
Type of probe’s thread M25х1,5
Height of measuring head above surface of
tank, including bumper ring, no more
mm 29
11, 12
Weight, no more g 250
12
Notes for table 1:
1. Allows you to measure different sorts of fuel with high electrical conductivity (which
contain anti-electrostatic additives).
2. The position of the upper (maximum) value of the measured level corresponds to the upper
edge of the drain hole of the probe.
3. Version of more than 800 mm is carried out to an additional order.
4. For version of "0800" (800 mm) it is allowed to shorten the probe "at the time of execution"
without restrictions on the minimum length.
5. During use of 16 bits representation of measurement results.
6. For a version of "0800" in the normal climatic conditions in accordance with ГОСТ15150-
69. In order to ensure a given accuracy in all working range of temperatures, the
adjustment of the calibration table should be applying (according to the temperature
dependence of the dielectric permeability of fuel).
It is also possible to adjust the calibration table with use of fuel with a dielectric permeability
different from the dielectric permeability of fuel which was used for calibration.
When testing the fuel with the same dielectric permeability as of the fuel used for calibration.
To ensure measurements with other sorts of fuel the adjustment of calibration table should
be used (according to dielectric permeability of the sort of fuel).
7. Data are given into two formats: 16 and 10/12 bits. Capacity of 10 or 12 bits is switched
according to the program. 12 bits value is set by default.
8. Pulse parameters in accordance to ГОСТ 28751-90 (product of A class, the degree of
severity 3 for 24V on-board power use).
9. With use of an additional inverter EG41 (42) U-mode or I – mode are possible. The
maximum output voltage Umax = U Power is 4 (V).
10. Other versions of conjunctive flange are possible after coordination with the customer.
11. Sealing gasket is not included.
12. For the indicated version of flange.
