4. Delivery set

4.1 Main delivery set

Table.2

Name Decimal number Quantity

Notes

1 Measuring head ES.100 1

2 Probe ES.200 1

3 Connecting cable ES.300 1

4 Flange ES.001 1

5 Cap ES.002 1

6 Self-drilling screw ES.004 1 With a hole for

sealing

7 Self-drilling screw 9Т64219-2 4

8 Gasket 5320-382713 1

9 Passport ES.402 ПС 1

10 Indicator’s seal SILTECH 2 With wire for

sealing

11 ZIP String

4.2

Extra Accessories

Table 3.

Name Decimal number

Notes

1) Service manual ES.401 RE

2) Compact disk CD-R ES.000 CD1 With program "eS Install" for

sensor’s setting

3) Cap М25х1.5 Installed on the tank after

removal of the sensor

4) Plug IEC ES.002.0 Installed on the tank after

removal of measuring head

5) Fuse 0,1А 250V Ø5х20 mm, high-speed
