RCS EPSILON ES4 User Manual

40
of a symbol protocol LLS (On/Off), averaging of data (On/Off) exchange rate on a serial port
(2400 ... 115 200 bit /s).
Command format:
Drift, byte
Size of field, byte
Value Description
0 1 31h Prefix
+1 1 00h…FFh
Network address of
acceptor
+2 1 55h Command code
+3 1 00h…FFh See table….
+4 1 00h…FFh CRC8
Answer format:
Drift, byte
Size of field, byte
Value Description
0 1 3Eh Prefix
+1 1 00h…FFh
Network address of
sender
+2 1 55h Command code
+3 1 00h or 01h
Return code: 00h -
command is complied
successfully, 01h -
Error
+4 1 00h…FFh CRC8
Data output mode decoding:
Bit(s)
Use
Description
Value by default
Notes
7 Output data capacity
0: 10 bit
1: 12 bit
ES2 – 10 bit
ES4 – 12 bit
Value by
default can be
changed
according to
order
6 Data averaging
0: ON
1: OFF
0 (ON)
5 Reserved - 0
Changes are
not allowed
4,3,2
Exchange speed on
serial port
000 – speed
does not change;
001 – 2400 bit/s;
010 – 4800 bit/s;
011 – 9600 bit/s;
(setting by
default);
100 – 19200
bit/s;
101 – 38400
bit/s;
110 – 57600
bit/s;
111 – 115200
bit/s;
100 (19200 bit/s)
Value by
default can be
changed
according to
order
