RCS EPSILON ES4 User Manual

EPSILON ES2,ES4
39
+1 1 00h…FFh
Network address of
acceptor
+2 1 50h Command code
+3 1 00h…FFh CRC8
Answer format:
Drift, byte
Size of field, byte
Value Description
0 1 3Eh Prefix
+1 1 00h…FFh
Network address of
sender
+2 1 50h Command code
+3 2 Vcc=0000h…7FFFh
Formula evaluation of
supply voltage:
U=Vcc/4667,8.
+5 1 00h…FFh CRC8
A2.3.2.1.6 Installing of the period of data output (command 54h).
The command is designed for setting of period of data output.
Command format:
Drift, byte
Size of field, byte
Value Description
0 1 31h Prefix
+1 1 00h…FFh
Network address of
acceptor
+2 1 54h Command code
+3 1 00h…FFh
Value of the period of data
output -1 s
+4 1 00h…FFh CRC8
Answer format:
Drift, byte
Size of field, byte
Value Description
0 1 3Eh Prefix
+1 1 00h…FFh
Network address of
sender
+2 1 54h Command code
+3 1 00h or 01h
Return code: 00h -
command is complied
successfully, 01h -
Error
+4 1 00h…FFh CRC8
A2.3.2.1.7 Installing of data output mode (command 55h).
The command is designed for setting of following parameters: data output capacity (10 or 12
bits), periodic data output (On/Off), resolution
