Configuration of the sensor as distance reader
To use the sensor as distance reader you have to:
 enter the programming menu (see on page 10);
 press ENTER to position on function F7;
 the red LED shows the current value of the function:
- if the red LED is lit the inversion is already enabled,
- if the red LED is off the inversion is disabled: press SET key to enable the inversion;
 position on function F10 and keep pressed ENTER key to save and exit.
 short-circuit the green and brown wires (as shown in the diagram on page 22, Configuration without
setpoint potentiometer section)
In this way the 0V regulated output corresponds to the minimum distance, instead the 10V regulated output
corresponds to the maximum distance.
