Re S.p.A. WG251 SKB-B RESMART
Rev. 05/15 17/25
Attention!
After about a minute of inactivity the functions menu window is disabled automatically.
For more information about the operation of the functions menu window see pages 12-13
Keep the enter key pressed for a few seconds to access the functions menu window
(the function number will be displayed in white, now you can scroll the functions with the +
or – keys). Use the enter key to exit the menu.
In the functions menu, use the write key to access each single function (the function
parameter will be displayed in white, at this point it can be changed with the + or – keys).
In the function press write to confirm the setting.
In the functions menu, use the + or – keys to scroll the menu functions (when the
display shows the function number in white).
In the functions press them to change the parameters set (when the display shows the
function value in white).
In the functions menu, after having selected the desired function, press the F
n
key to
associate the function to this key.
Now it will be possible to recall the function without accessing the functions menu, but by
simply pressing the F
n
key in the operating window (only possible if in the F.8 function it
has been enabled, by setting 1 )
The F.50 Calibration, F.51 Complete Servo Center , F.52 Regulation inversion and F.90
Password functions cannot be associated to the F
n
key.
