Re WG251 SKB-B RESMART User Manual

Re S.p.A. WG251 SKB-B RESMART
Rev. 05/15 16/25
Programming and calibration funcions
This section describes the programming and calibration functions available for the WG251 SKB-B
RESMART system.
Funct.
Description
Range of values
Default settings
F.1
Motor speed
1÷95 if F.32=0
1÷120 if F.32=1
50
F.2
Dead zone
0÷Zslow
6
F.3
Slow zone
Zdead÷60
10
F.5
Interrupted line
0=Off - 1=On
0=Off
F.6
Stop period
1÷100 - Infinite
Infinite
F.7
Setup block
0=Off - 1=On
0=Off
F.8
F
n
function
0=Off - 1=On
1=On
F.10
Servo Center offset
0÷100
50
F.11
Last status memo
0=Off - 1=On
0=Off
F.12
AUTO at power up without material
0=Off - 1=On
1=On
F.14
MAN motor inversion
0=Off - 1=On
0=Off
F.15
Remote controls
0=Off - 1=On
2=enabling the controls with
automatic key, disabling the
controls with manual key
3=On (AUTO and MAN
separate and Servo Center)
4=On (AUTO/MAN, Servo
Center and keys block)
4=On (AUTO/MAN,
Servo Center
and keys block)
F.20
Sensor selection
1=Sensor 1
2=Sensor 2
3=Centre guide
1=Sensor 1
F.21
Sensor 1 field of view
5÷30
15
F.22
Sensor 2 field of view
5÷30
15
F.30
Enable complete
0=Off - 1=On
0=Off
F.31
Motor power
1÷4
2
F.32
Enable high speed
0=Off - 1=On
0=Off
F.50
Calibration
See procedure on page 20
F.51
Complete Servo Center
The actuator moves to the right, to the left and stops in
the desired position (set on F.10)
F.52
Regulation inversion
0=Off - 1=On
0=Off
F.60
Display brightness
1÷15
5
F.90
Password
0÷255
0
F.91
Reset MWG10
See procedure on page 22
F.92
Diagnostics
Displays the system values
F.99
Firmware version
Displays the firmware version of the MWG10 device
