13 Technical data
REA TD-GPT-U
Print head Fix mounted thermal print head
Paper/print width/ diameter Thermal paper: 57,0 ± 0,5mm / 48mm / max. 31mm /
about 11 m in case of 60 g/m
2
Resolution 8 dots / mm (203 dpi) , 384 dots / Print line
Print speed up to 50mm/s / 16 lines/s line / 3mm, i.e. 24 print lines
high
Layout options Text; graphics, Text-/data mode; bar code; gray on
white; inverted white on black, characters spread in
height and width
Character sets, cpl 24 (32, 42, or 54) select by control command or menu
Barcode Code39, 2/5int, EAN13, EAN8
Interface Internal USB to serial converter, Parameter: Baud rate:
1200, 2400, 4800, 9600, 19200, 38400, 57600 and
115200 Data: 7, 8; Stop bits: 1, 2; Parity: non, odd,
even
Handshake: Hardware and XON / XOFF
Buffer 255 Byte
Data compression (PCL) Factor ca. 3 :1 (for printing graphics)
Batteries Rechargeable battery pack 4x NiMH cells, 1500 mAh
Max charging temperature 30 °C
Power supply Unregulated socked power supply 6V, 500 mA
Current drain USB Online Idle-Mode: typ. 10 mA; Sleep-Mode: typ. 25
µA; Power-Off-Mode: < 1 µA
Environment 0 °C up 50 °C
(-10 °C up to +60 °C with special paper)
10 % to 80 % rel. Humidity, not condensing
MTBF 50 km paper use
Sizes in mm 76,8 mm x 77,4 mm x 39,3 mm
Weight approx. 350 g paper roll incl.
Housing PC-ABS with 15 % glass fibre, black
