Wiring Connections
Primary Harness (H1), 9-pin connector
H1/1
LIGHT GREEN BLACK (-) 200mA FACTORY ALARM DISARM
H1/2
GREEN/WHITE (-) 200mA FACTORY ALARM REARM
H1/3
EMPTY NOT USED
H1/4
WHITE/BLUE (-) ACTIVATION INPUT
H1/5
EMPTY NOT USED
H1/6
EMPTY NOT USED
H1/7
EMPTY NOT USED
H1/8
BLACK GROUND
H1/9
WHITE (+/-) LIGHT FLASH OUTPUT
Heavy Gauge Relay Harness (H2), 6-pin connector
H2/1
PINK OUTPUT TO PRIMARY IGNITION CIRCUIT, 30A (+)
H2/2
PURPLE OUTPUT TO STARTER CIRCUIT, 30A (+)
H2/3
ORANGE OUTPUT TO ACCESSORY CIRCUIT, 30A (+)
H2/4
RED (+) (30A) HIGH CURRENT 12V INPUT
H2/5
PINK/WHITE PROGRAMMABLE OUTPUT, 2ND IGNITION/ACCESSORY
CIRCUIT 30A
H2/6
RED (+) (30A) HIGH CURRENT 12V INPUT
Auxiliary Harness (H3), 5-pin connector
H3/1
BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
H3/2
VIOLET/WHITE TACHOMETER INPUT WIRE
H3/3
BROWN (+) BRAKE SHUTDOWN INPUT WIRE
H3/4
GRAY (-) HOOD PIN SWITCH SHUTDOWN WIRE
H3/5
BLUE/WHITE (-) 200 mA STATUS/REAR DEFOGGER
