realspace 7500109 - Assembly Instructions; Install Desk Structure

Insert the lifting columns completely before
rotation, avoiding height differences.
The long side of the lifting column is parallel
to the short side of the tabletop.
2
1
The long side of
the lifting column
The short side of
the tabletop
Install the lifting columns (2) to the tabletop set (1),
and tighten the screws (B) with an Allen key (E).
2
3
1
E
Insert the hexagon head of lifting
columns along the guide groove
Tighten
Use a 4x4 Allen key to tighten 8 screws (B).
Assembly Instructions
Step 1
Install the lifting column
4x4
B
x8
E
x1
8
