1.Introduction
ThisdocumentillustrateshowtobuildRealteklowpowerWi‐FisoftwareunderIARSDK
environment.
2.HowtogetIAR
IARprovidesanIDEenvironmentforcodebuilding,downloading,anddebugging.Pleasecheck
“IAREmbeddedWorkbench”onhttp://www.iar.com/,andtrailversionisavailable.
3.Ameba‐ZHardwareConfiguration
HardwareblockdiagramisshowninFigure3‐1Hardwareblockdiagram.TheblockUSBUARTis
usedtosupplypowerandcatchlogs,UARTbaudis115200.SWDmeansJ‐LinkSWDinterface,
whenitisconnectedtoJ‐LinkAdaptercorrectly,youcandownloadimagestoAmeba‐ZfromIAR
flashdownloader.ResetbuttonisusedtoresetAmeba‐Ztorunfirmware afterIARcompletes
downloading.

Figure3‐1Hardwareblockdiagram
TheDupontLinediagrambetweenJ‐LinkAdapterandAmeba‐ZSWDisasfollows:
