rec tec grill RT-680 - Stand Grill Upright and Install Handles; Install Smoke Stack

STEP 6 – Stand Rec Tec Grill Upright
After completing the Smart Grill Technology™ installation in Step 5, stand the grill upright.
You will need two people to do this as the grill is very heavy.
STEP 7 – Bull Horn Handle Assembly
Attach bull horn handles 6 and 7 to grill body using 4 small bolts (M6 x 16). (See Bolt Assembly
Order diagram.) There is a left and a right handle. Proper placement will result in the handle facing
inward with the tip slightly upward
.
6
10
2
7
1
STEP 8 – Install Pull Handle
Attach the pull handle !0 using the two bolts that are screwed into the handle.
STEP 9 – Install Smoke Stack
Install the smoke stack 2 using 2 short bolts (M10 x 16). (See Bolt Assembly Order diagram.)
7 ©2014, Rec Tec Industries, LLC
