7
Connect to your earbuds or Φ3.5mm stereo-mini
plug. When tape-recording the sound of record,
connect to the device which uses connector code of
Φ3.5mm stereo-mini plug.
* After connecting the plug to this terminal, no
sound will come out of the speaker.
Connect to DC plug of supplied AC adaptor.
It is the dial to tune the rotation speed of record to
the speed specified by record. Tune the dial to the
number shown on the cabinet.
* When not playing the record, be sure to tune the dial
to OFF position.
Before use
●Prepare power source
Use domestic power source or dry cell battery.
Remove back cover
Slide the back cover at the bottom and pull out
to the direction of arrow.
When using AC adaptor
Connect DC plug of supplied AC adaptor to DC
power input terminal on the side face of the
device.
When using dry cell
Connect supplied AC adaptor to AC 100V
power outlet.
* Note that battery is not supplied. We
recommend using alkaline AA battery.
Please prepare six alkaline AA batteries.
Install six AA batteries in correct polarity.
Close the back cover.
* Do not touch AC adaptor with wet hand to
prevent electrical shock.
* Please connect to easy-to-reach power outlet
so that you can unplug in an emergency.
