PARTS LIST
1. Large base frame
2. Small base frame
3. Base screws x 2
ASSEMBLY AND USE
1. Connect the two base frames together and secure with the two screws. Fig 1.
2. Slot the tubes of the swing frame into the base frame. To release it, press the red
button and lift upwards. Fig 2.
3. Connect the head frame tubes of the seat into the tubes of the swing frame. Wrap
the front of the seat around the frame tube of the swing and secure with the two sets
of straps. Fig 3.
4. To adjust the recline position, press the button in and raise or lower the seat to the
desired position. There are three to choose from. The lowest position is suitable for
napping, the middle for feeding and the high position for play. Fig 4.
5. To fold the swing for storage, gently push the top of the seat forward whilst pushing in
the red release button and then pull out the bar. The seat will now fold down. Fig 5.
6. Insert the end of the power adapter (AC 100-240V – 50/60Hz) into the swing
and insert the plug into a 240v wall socket. Fig 6.
7. To secure and adjust the harness. Slide shoulder strap (A) on to waist strap (B) then
insert into the central buckle (C). Press the button on the central buckle (C) to release
the harness. To acheive a snug and secure t, use the sliders located on the harness
straps. Fig 7.
4. Swing frame
5. Seat and head frame
6. Remote control
7. Adapter
1 2 3 4 5
6 7
