The Red Kite Siesta Swing is an infant swing designed for babies from birth up to 6 months old, weighing less than 9kg (20lbs), who cannot sit up unaided. It complies with EN 16232: 2013 + A1: 2018 safety standards. The swing's primary function is to soothe and entertain babies, offering various features for comfort and convenience.

Function Description:

The Siesta Swing provides a gentle swinging motion with adjustable speeds and includes built-in melodies to entertain the baby. It features a recline function to adjust the seat position for napping, feeding, or play. The swing can be powered via an AC adapter or batteries, offering flexibility in usage. A remote control is included for convenient operation.

Important Technical Specifications:

Age/Weight Range: From birth to 6 months, weighing less than 9kg (20lbs). Discontinue use when the child can sit up unaided.
Power Supply: AC 100-240V – 50/60Hz (adapter output DC 6V/1A) for the swing's control panel. The remote control uses 1x CR2025 3V button battery.
Swing Speeds: 8 adjustable swing speeds.
Melodies: 9 built-in melodies with adjustable volume (8 levels).
Timer Settings: 5, 10, 15, 20, 25, 30, 35, and 40 minutes.
Recline Positions: 3 recline positions (lowest for napping, middle for feeding, high for play).
Safety Standards: Complies with EN 16232: 2013 + A1: 2018.

Usage Features:

Assembly: The swing consists of a large base frame, a small base frame, a swing frame, and a seat and head frame. The base frames connect with two screws. The swing frame tubes slot into the base frame and are released by a red button. The head frame tubes of the seat connect to the swing frame, and the seat wraps around the swing frame tube, secured by two sets of straps.
Recline Adjustment: A button allows for adjusting the seat to one of three recline positions: lowest for napping, middle for feeding, and high for play.
Folding for Storage: To fold, gently push the top of the seat forward while pressing the red release button and pulling out the bar.
Power Connection: Insert the power adapter into the swing's control panel and plug it into a 240V wall socket.
Harness System: A 5-point harness system (shoulder straps, waist straps, central buckle) is provided to secure the baby. Sliders on the straps allow for a snug and secure fit. Always use the harness.
Control Panel:
- Power Button: Turns the swing on/off. Illuminates white when on.
- Timer Button: Activates the timer function (5 to 40 minutes in 5-minute increments). Use "+" and "-" buttons to select the desired duration.
- Melodies Button: Starts playing 9 built-in melodies automatically. Press again to skip to the next melody. Press and hold to turn off. The swing remembers the last played melody. Volume can be adjusted using "+" and "-" buttons (8 levels).
- Swing Speed Button: Activates the swing function. Use "+" and "-" buttons to adjust between 8 swing speeds. Selecting "0" turns off the swing function.
- Automatic Lock: If the control panel and music are inactive for 1 minute, the system locks automatically. To unlock, simultaneously press the melodies and timer buttons.
Remote Control: The remote control mirrors the functions of the control panel, including power on/off, timer, melodies, volume control, and swing speed adjustment. It requires pointing directly at the control panel to function. Remember to pull the PVC tab to activate the battery before first use.
Safety Warnings:
- Never leave the child unattended.
- Do not use on an elevated surface (e.g., a table).
- Not intended for prolonged periods of sleeping; if the child needs to sleep, place them in a cot or bed.
- Always use the restraint system.
- Do not move or lift the product with the baby inside it.
- Do not use once the child can sit up unaided or weighs more than 9 kg.
- Keep children away when unfolding and folding.
- Not recommended for children who can sit up by themselves (approx. 6 months, 9kg/20lbs).
- Never use the toy bar to carry the swing.
- Do not expose to heat sources like open fires or hot ovens/stoves.
- Keep children away during set-up and accessory fixing.
- Never use as a child restraint in any vehicle.
- Guard trailing electrical flexes.
- Do not use near stairs or steps.
- Do not adjust with the baby in the swing.
- Ensure safety straps are fastened and correctly adjusted.
- Do not let children play with this product.
- Ensure the battery compartment is secured with a screw before use.
- Remote control is not a toy and should be managed by an adult.

Maintenance Features:

General Care: Store in a dry place to prevent mould or mildew. Avoid prolonged direct sunlight to prevent premature fading.
Cleaning:
- The seat cover and toys are removable and can be washed on a cool, gentle cycle.
- Metal parts can be cleaned with a damp cloth and wiped dry with a soft cloth.
- Harness, toys, and toy bar can be cleaned with mild soap and water solution, then rinsed and wiped dry.
- Plastic parts can be cleaned with mild soap and water solution, then rinsed and wiped dry.
- Do not use abrasive cleaners or bleach.
Inspection: Regularly check for broken, torn, or missing parts, sharp edges, loose or damaged fittings, and damaged straps/harness attachment points. Stop using the swing immediately if any issues are found.
Replacement Parts: Only use replacement parts approved by the manufacturer or distributor to avoid invalidating the warranty.
Battery Information (for remote control):
- Batteries must be installed by an adult.
- Keep batteries and tools out of reach of babies and children.
- Remove spent batteries to avoid leakage and damage.
- Remove batteries if the toy will not be used for a long period.
- Use only alkaline batteries of the recommended type.
- Do not mix new and old or different types of batteries.
- Ensure correct polarity when fitting new batteries.
- Do not burn or dispose of spent batteries into the environment; dispose of them at an appropriate collection point.
- Do not short circuit battery terminals.
- Do not attempt to recharge non-rechargeable batteries.
- Remove exhausted batteries from the toy.
- Remove rechargeable batteries from the toy before charging.
- Rechargeable batteries should only be charged under adult supervision.
- Recycle waste products where facilities exist; do not dispose of with household waste.
