ASSEMBLING&INSTALLINGYOURORBITPOOLCLEANER
STEP1:CHECKCONTENTS
Removethecleanerbodyandallparts
fromtheboxandcheckthefollowing
componentsareincluded.Referto
Figure1.
Figure1
STEP2:ASSEMBLETHEORBITPOOLCLEANER
ToassemblesimplyfityourOrbitpool
cleanerdisctothebody.
Simplystretchthedisc(withthefins
pointingup,towardsthecleaner)overthe
Footpad,asshowninFig2.Makesurethe
insiderimoftheDiscislocatedinthe
trackthatrunsaroundtheFootpad.When
theDisciscorrectlypositioned,itshould
easilyrotatearoundtheFootpad.
Figure2
PAGE3
DISC
FOOTPAD
NO:
Description
Quantityof
components
1
2
3
4
5
6
7
8
9
CleanercompletewithFootpad
Disc
Hoselengths*
DeflectorWheel
HoseWeight
ReturnLineDiverter
ControlValveAdaptor
FlowControlValve
1
1
12
1
3
1
1
1
1Hoseadaptor
*
F20001Orbitcompeteonly;notincludedwith
F20002OrbitHeadonly(nohose)
