RED 585-160 - DVD Player Parts and Controls

3
2. COMPATIBILITY 3. EXPLANATION OF DVD SYMBOLS
This DVD player is compatible with the following disc types
DVD 8 & 12cm Single sided, single and doubled layered
8 & 12cm Double sided, single layered
CD – DA 8 & 12cm discs
CD-R / CD-RW
CD-MP3
CD – Kodak picture
4. PARTS
DVD PLAYER
1. Disc tray
2. Previous () button
3. Next () button
4. Disc tray open / close (
) button
5. Power ( ) button
6. Play/Pause ( ) button
7. Stop (■) button
8. Remote sensor
1. Audio output (L)
2. Audio output (R)
3. Composite video output
4. HDMI output
5. Power cable
6. SCART socket
Region code
Dolby Digital Surround
Number of Audio Tracks
Number of Sub-titles
Screen Format
Angle Indicator
1
2
3
4
5
7
8
6
