RED COMPACT 24 - Auto Eco Mode

red
COMPACT 24 BOILER
Chapter
9
USE AND MAINTENANCE MANUAL page 44
Programming and settings Technical dept. - All rights reserved - Reproduction prohibited
PROGRAMME 1 (6:30-8:00 Mon, Tues, Wed, Thur, Fri)
DESCRIPTION PRESS STEP DISPLAY CONFIRM
Entering the programming sequence Key 3 UT 01 Day 1…Day 7..Off
Today is Thursday (Day 4) Btn 1 or Btn 2 UT 01 Day 4 Btn 3
The time now is 18 and... Btn 1 or Btn 2 UT 02 18 Btn 3
12 minutes Btn 1 or Btn 2 UT 03 12 Btn 3
Unused step (for maintenance) UT 04 Btn 3
Programme 1: boiler switch-on time 6:30 (hot at 7:00) Btn 1 or Btn 2 UT 05 6:30 Btn 3
Programme 1: boiler switch-off time 08:00 (cold at 08:30) Btn 1 or Btn 2 UT 06 08:00 Btn 3
Programme 1: day ON Monday Btn 2 UT 07 ON 1 or OFF 1
Programme 1: day ON Monday Btn 1 UT 07 ON 1
Programme 1: day ON Tuesday Btn 2 UT 07 ON 2 or OFF 2
Programme 1: day ON Tuesday Btn 1 UT 07 ON 2
Programme 1: day ON Wednesday Btn 2 UT 07 ON 3 or OFF 3
Programme 1: day ON Wednesday Btn 1 UT 07 ON 3
Programme 1: day ON Thursday Btn 2 UT 07 ON 4 or OFF 4
Programme 1: day ON Thursday Btn 1 UT 07 ON 4
Programme 1: day ON Friday Btn 2 UT 07 ON 5 or OFF 5
Programme 1: day ON Friday Btn 1 UT 07 ON 5
Programme 1: day ON Saturday Btn 2 UT 07 ON 6 or OFF 6
Programme 1: day ON Saturday Btn 1 UT 07 OFF 6
Programme 1: day ON Sunday Btn 2 UT 07 ON 7 or OFF 7
Programme 1: day ON Sunday Btn 1 UT 07 OFF 7
Programme 1: CONFIRM UT 08 Btn 3
PROGRAMME 2 (11:30-13:00 Mon, Tues, Wed, Thur, Fri)
DESCRIPTION PRESS STEP DISPLAY CONFIRM
Programme 2: boiler switch-on time 11:30 (hot at 12:00) Btn 1 or Btn 2 UT 05 11 : 30 Btn 3
Programme 2: boiler switch-off time 13:00 (cold at 13:30) Btn 1 or Btn 2 UT 06 13 :00 Btn 3
Programme 2: day ON Monday Btn 2 UT 07 ON 1 or OFF 1
Programme 2: day ON Monday Btn 1 UT 07 ON 1
Programme 2: day ON Tuesday Btn 2 UT 07 ON 2 or OFF 2
Programme 2: day ON Tuesday Btn 1 UT 07 ON 2
Programme 2: day ON Wednesday Btn 2 UT 07 ON 3 or OFF 3
Programme 2: day ON Wednesday Btn 1 UT 07 ON 3
Programme 2: day ON Thursday Btn 2 UT 07 ON 4 or OFF 4
Programme 2: day ON Thursday Btn 1 UT 07 ON 4
Programme 2: day ON Friday Btn 2 UT 07 ON 5 or OFF 5
Programme 2: day ON Friday Btn 1 UT 07 ON 5
Programme 2: day ON Saturday Btn 2 UT 07 ON 6 or OFF 6
Programme 2: day ON Saturday Btn 1 UT 07 OFF 6
Programme 2: day ON Sunday Btn 2 UT 07 ON 7 or OFF 7
Programme 2: day ON Sunday Btn 1 UT 07 OFF 7
Programme 2: CONFIRM UT 08 Btn 3
PROGRAMME 3 (16:30-21:30 Mon, Tues, Wed, Thur, Fri)
DESCRIPTION PRESS STEP DISPLAY CONFIRM
Programme 3: boiler switch-on time 16:30 (hot at 17:00) Btn 1 or Btn 2 UT 05 16 : 30 Btn 3
Programme 3: boiler switch-off time 21:30 (cold at 22:00) Btn 1 or Btn 2 UT 06 21 :30 Btn 3
Programme 3: day ON Monday Btn 2 UT 07 ON 1 or OFF 1
Programme 3: day ON Monday Btn 1 UT 07 ON 1
Programme 3: day ON Tuesday Btn 2 UT 07 ON 2 or OFF 2
Programme 3: day ON Tuesday Btn 1 UT 07 ON 2
Programme 3: day ON Wednesday Btn 2 UT 07 ON 3 or OFF 3
Programme 3: day ON Wednesday Btn 1 UT 07 ON 3
Programme 3: day ON Thursday Btn 2 UT 07 ON 4 or OFF 4
Programme 3: day ON Thursday Btn 1 UT 07 ON 4
Programme 3: day ON Friday Btn 2 UT 07 ON 5 or OFF 5
Programme 3: day ON Friday Btn 1 UT 07 ON 5
Programme 3: day ON Saturday Btn 2 UT 07 ON 6 or OFF 6
Programme 3: day ON Saturday Btn 1 UT 07 OFF 6
Programme 3: day ON Sunday Btn 2 UT 07 ON 7 or OFF 7
Programme 3: day ON Sunday Btn 1 UT 07 OFF 7
Programme 3: CONFIRM UT 08 Btn 3
