8-MENU ITEMS
CONTROL PANEL DISPLAY
Menu items
KEY
1. Boiler lighting/shutdown
2. Scrolling of programming menu to decrease.
3. Menu
4. Scrolling of programming menu to increase.
5. Decrease set temperature/programming functions.
6. Increase set temperature/programming functions.
7. Display.
MAIN MENU
It is accessed by pressing key 3 (menu). The items that are accessed are:
• Date and Time
• Timer
• Sleep (only with the boiler on)
• Settings
• Info
Date and time setting
To set the date and time act as follows:
• Press the “menu” button.
• Select “Date and Time”.
• Select by pressing “menu”
• Scroll with the arrows and select the variables to be modied one at a time: Day, Hours, Minutes, Day number, Month, Year.
• Select “menu” to conrm.
• Modify with the + - keys.
• Finally press “menu” to conrm and “esc” to exit.
