F
G
50
13 - MAINTENANCE AND CLEANING
PERIODIC CLEANING PERFORMED BY A QUALIFIED TECHNICIAN
CLEANING THE HEAT EXCHANGER
The compartment through which the exhaust smoke passes must be cleaned at the end of the winter season.
This cleaning process is mandatory in order to facilitate the general removal of all combustion residue, before it becomes very dicult to
remove it due to the humidity compacting it over time.
If necessary, clean it more often.
CAUTION:
It is obligatory to have an authorised and skilled technician perform the periodic end-of-season cleaning in order to
replace any worn gaskets.
CLEANING THE UPPER EXCHANGER:
When the stove is cold open the door, remove plate “F” (removing the two screws). To remove plate “G” the door must be removed (see
suitable chapter for removal).
After the plates have been removed, use the brush supplied to scrape the exchanger walls so that the ash falls in the lower compartment.
