22
4-INSTALLATION AND ASSEMBLY
PREPARATION AND UNPACKING
The Primula/Gardenia and Orchidea/Margherita stoves are delivered with two dierent types of packing:
GARDENIA and PRIMULA stoves come in 1 pack
• It contains the stove and also the steel sides with the proles (g.1)
The ORCHIDEA and MARGHERITA stoves come in 2 packs
• One contains the stove
• One contains the ceramics (g.2). In this case there will be a single pack for the structure (the box with the ceramics will be placed
on top of the pack with the structure)
Open the pack, remove the four screws that secure the base of the stove to the pallet, two to the right and two to the left (see gure 3) and
position the stove in the selected place, ensuring that it complies with the above instructions.
FIGURE 2 - EXAMPLE OF CERAMICS PACK-
AGING
FIGURE 1 - EXAMPLE OF STOVE + STEEL
SIDES PACKAGING
FIGURE 3 - REMOVAL OF PACKAGING
SCREWS
