9 - PRELIMINARY NOTIONS
CONFIGURATION 5
1 RED HYDRO STOVE
2 HEATING DELIVERY
3 HEATING RETURN
4 ZONE VALVES
5 HEATING BODIES
6 DOMESTIC HOT WATER
7 COLD DOMESTIC WATER
8 DOMESTIC WATER BOILER
9 DIVERTER VALVE
10 BOILER THERMOSTAT
11 THERMOSTATIC MIXING VALVE
12 DOMESTIC WATER 10 k β3434 NTC PROBE
13 HEATING PUFFER
14 HEATING SYSTEM CIRCULATOR
15 PUFFER THERMOSTAT
16 PUFFER 10 k β3434 NTC PROBE
17 SAFETY VALVE
