CAMERA TOP

Figure: Camera Body Controls and Features

# ITEM DESCRIPTION

7 Primary

EVF/LCD

Port

Mount a DSMC2 RED Touch LCD, LCD/EVF Adaptor A, or LCD/EVF Adaptor D

8 Top Handle

Port

Mount the DSMC2 Top Handle or DSMC2 Outrigger Handle. This is the only mounting option for the

DSMC2 Top Handle or DSMC2 Outrigger Handle (it cannot be attached backward)

9 Fan intake DO NOT block fan intake when the camera is on

C OPYRIGH T © 20 20 R ED .COM, LL C 95 5- 0192_V7 .3 , R EV- A | 12

RED RANGER GEMINI OPERATION GUIDE
