2 INSTALLATION GUIDE

Wall Mount

Use the template provided (section4 on

page37) to mark the position and drill and

cut the mounting holes into the wall.

Attach the Back Plate to the wall using 4

suitably sized countersunk screws.

3 4

Feed the Remote Monitor cable through the

hole and connect it to the Remote Monitor.

Clip the Inner Assembly into the Back Plate.

5 6

Clip the Front Face to the Inner Assembly.

FIGURE 2.2.2.2: How to wall mount the Remote Monitor.
