Redarc BMS1230S3-NA User Manual

7
1 INTRODUCTION
1.4 Specifications
Electrical Specifications
Inputs
AC Input
Input Voltage Range (nominal) 110 to 120VAC, 50 to 60Hz
Power Rating 560W
Efficiency 80% to 90%
Connection IEC Mains Plug
DC Input
Input Voltage Range 9 to 30 VDC
Turn ON/OFF Threshold 12V (24V) 13.2V / 12.7V (26.4V / 25.4V)
Power Rating 520W
Efficiency 94%
Connection Phoenix 1967498 Connector
Solar Input
Input Voltage Range 9 to 30 VDC
Turn ON (Open Circuit Voltage) 9.5V
Power Rating 520W
Efficiency 93%
Connection Phoenix 1967498 Connector
Output
Total Battery Capacity 40 to 800Ah
Output Battery Volts (Nominal) 12V
Output Battery Volts (Minimum) 0.1V
Output Current (Nominal) 0 to 32A
Maximum Current on Load Disconnect Wire 1A
Memory Save on Battery Disconnect Yes
Output Protection
Short Circuit Protection Yes
Surge Protection Yes
Reverse Polarity Protection Yes
Overload Protection Yes
Max Volts @ Battery Terminals (25 °C Nominal) Storage Mode Touring Mode Float
Gel Setting 14.4V 14.4V 13.5V
AGM Setting 14.4V 14.4V 13.5V
Calcium Setting 16.0V 15.2V 13.5V
Standard Lead Acid Setting 15.5V 14.8V 13.5V
Lithium Setting 14.5V 14.5V 13.6V
Thermal Specifications
Operating Temperature −40 °F to 176 °F (−40 °C to 80 °C)
Sealed Lead Acid (SLA), AGM, or Calcium
Charging Temperature
−13 °F to 140 °F (−25 °C to 60 °C) (when Vop >10.5V)
SLA, AGM, Gel, Calcium or LiFePO
4
Charging Temperature 32 °F to 140 °F (0 °C to 60 °C)
Over Temperature Shutdown Yes
Temperature Compensation
Standard Lead Acid, AGM, Gel or Calcium Battery +16.7mV / °F < 77 °F < −16.7mV / °F (+30mV / °C < 25 °C < −30mV / °C)
Lithium Setting −40 °F < 0.28% / °F < 140 °F (40 °C < 0.5% / °C < 60 °C)
Compliance
EMC FCC, CAN ICES-3 (B)/NMB-3(B)
Safety UL Listed (Canada, USA)
Environmental RoHS Compliant
General Specifications
Main Unit Dimensions 17.5" × 7.3" × 3.1" (445 × 185 × 79mm)
Remote Monitor Dimensions 7.3" × 2.9" × 1.1" (186 × 74 × 29mm)
Kit Weight 12.1lbs (5.5kg)
Warranty 2 years
