2 USER GUIDE
2.1 Front Panel Operation
WARNING: RISK OF ELECTRICAL SHOCK. DO NOT DISASSEMBLE THE INVERTER — THE INTERNAL CIRCUITRY
CONTAINS HAZARDOUS VOLTAGES. ATTEMPTING TO SERVICE THE UNIT YOURSELF MAY RESULT IN ELECTRIC SHOCK
OR FIRE AND WILL VOID THE UNIT WARRANTY.
3
2
5
1
6
4
FIGURE 2.1.1: 1000W Models
3
2
5
1
6
4
FIGURE 2.1.2: 1500/2000W Models
4
3
2
5
1
6
FIGURE 2.1.3: 3000W Models
1000W 1500W 2000W 3000W
1 Main Switch
2 Indicator LEDs
3 Function Switch
4 Power Save Adjustment
5 TRC Port (RJ45)
6
1000W/1500W/2000W 3000W
AC Output Socket AC Output Terminals
