8
1 INTRODUCTION
Model: R-12-3000RS-NA
Input
Characteristics
Max. Rated Input Current 318A
Voltage 12V DC
Over-Voltage Protection 16.5±0.3V DC
Under-Voltage Protection 10.5±0.3V DC
Voltage Range 10.5~16.5V DC
No Load Current ≤3.8A @ 12V DC
Power Saving Mode <0.4A @ 12V DC
Output
Characteristics
Continuous Output Power 3000W (VA) (±3%)
Maximum Output Power (1 min) >3000~3450W (VA) (100%~115%)
Surge Power (<1 sec) <6000W (VA)
Frequency 50/60Hz±0.5% (Dip Switch Selectable)
Output Voltage
100/110/115/120V AC (±5%)
(Dip Switch Selectable)
Efficiency Max 90%
Short-Circuit Protection 1 Sec Shutdown
Output Waveform
(1)
Pure Sine Wave (THD<5% @ Normal Load)
Signal and
Control
Remote Controller Panel Input REMOTE-RS (optional)
LED Indicator Red/Orange/Green LED
Dry Contact Terminal By a relay
Remote Control Terminal 6-port Green terminal (for inverter ON/OFF)
Protection
Input Protection
(2)
Over/Under Voltage, Reverse Polarity
(Internal Fuse)
AC Output Protection Short-Circuit, Overload
Others
Over/Under Temperature Protection (by Heat
sink Temperature 176°F (80°C)/–4°F (–20°C))
Environment
Operating Temp.
–4~104°F — Derates to 140°F
(–20~40°C — Derates to 60°C)
Storage Temp. –22~158°F (–30~70°C)
Storage Temp. and Humidity 10~95%RH
Safety and EMC
Safety Standards
(3)
UL 458 (provided used with approved
GFCI connector) C22.2 No. 107.1
EMC Standards
(4)
FCC Class A, CAN ICES-003 (A)/NMB-003(A)
Weight 18 lb (8.2kg)
Cooling Temperature and Load Controlled cooling Fan
Dimensions (W×H×D) 10.1"×6.2"×17.4" (255×158×442mm)
(1) Normal load condition: Vin=12.5V/25V/50V, Vo=100/110/115/120 V AC 80% load (PF=1.0)
(2) Reverse polarity connection can blow the internal fuse and may damage the inverter permanently.
(3) Ground Fault Circuit Interrupter (GFCI) see 2.1.6 on (page 16).
(4) Refer to page 26 for compliance information.
