8) Handlebars (cont.)
b. Install (2) upper handlebar clamps and (4) 10mm hex head bolts.
c. Position handlebars to desired angle.
d. Tighten (4) 10mm hex head bolts.
9) Side Front Fender Brace
a. Install 10mm hex head bolt through slot in fender brace into frame.
i.
IMPORTANT – Install both sides before tightening.
b. Tighten both sides.
17
