1.0 TECHNICAL SPECIFICATIONS
Model
7113
Working width 1.34 mtr (54”)
Working depth Up to 150 mm (6”)
Tractor speed @ 500 rev’s at PTO
Hole spacing 55 mm (2-1/8”)
Hole spacing 90 mm( 3 ½”)
Hole spacing 125mm(5”)
Up to 2.0 km/h (1.25 mph)
Up to 3.2 km/h (2.0 mph)
Up to 4.3 km/h (2.7 mph)
PTO speed
Up to 500 rpm in 1st and 2nd gear, 400 rpm in 3rd.
Weight 520 Kg (1145 lbs)
Hole spacing side-to-side 55 mm (2-1/8”)
Hole spacing in driving direction 25 – 125 mm ( 1 - 5”)
Recommended tractor size 25 HP with lift capacity of minimum 650 Kg
( 1450 lbs)
Capacity (maximum)
Spacing 55 mm (2-1/8”)
Spacing 90mm (3 ½ “)
Spacing 125mm (5”)
Up to 2650 sq.mtr (24000 sq ft)/ hour
Up to 4200 sq.mtr (38300 sq.ft)/ hour
Up to 5690 sq.mtr (51900 sq.ft)/ hour
Shipping dimensions 1550 x 750 x 1050 mm
(62”x 30”x 42”)
Maximum tine size Solid 12 x 150 mm (1/2”x 6”)
Hollow 19 x 150 mm (3/4”x 6”)
Slip clutch setting PTO Maximum 400 Nm. (3540 lb.inch.)
Three point linkage 3- point CAT 1
Transmission oil Life time grease EP 00
Lubrication grease EP 2
Standard items Set solid tines 12/150 (1/2”x 6”)
Front and rear roller with scrapers
3- shuttle gearbox
Toolbox with combi tool
