RedMax BC225DL - Optional Blade Usage and Control

Under
growth
Heavy
weeds
Light
weeds
Grass
Nylon line
head
CUTTER
APPLICATION
CHART
9” 22-tooth:
SST229
9” 24-tooth:
SST249
8” 8-tooth:
SGB088
9” 8-tooth:
SGB089
8” 4-tooth:
SGB048
9” 4-tooth:
SGB049
11. Optional blade usage
■ CHOOSE THE BLADE
Choose a suitable recommended cutting
attachment according to the object to be cut.
(OPT1)
• When replacing blade always be sure to use
products which have been certified by RedMax.
• When using the metal blade, make sure to
install the hanger and the shoulder strap.
■ SET UP THE HANGER (OPT2, 3)
1. Loosen the screws and remove the guard.
2. Loosen the screws and remove the gearcase.
3. Loosen the screws and take the loop handle off.
4. Install the hanger complete from the blade side
end and fix it with the screw.
5. Reinstall the gearcase.
(1) Hanger complete: 6420-17400
(2) Shoulder strap: T3002-17200
WARNING
OPT1
25 
OPT2
OPT3
