RedMax BC225DL - Page 33

Key# Description Part Number Q'ty
Fig.1 DRIVE UNIT BC225DL (S/N 120000 and up)
Key# Description Part Number Q'ty
1 PIPE COMP T3108-12100 1
2 SHAFT 3520-12213 1
3 GEARCASE-ASS’Y T3108-13001 1
4 • GEARCASE T3300-13120 1
5 • BEARING T3300-13510 1
6 • BEARING T3300-13520 1
7 • RING 04065-02612 1
8 • SHAFT COMP T3300-13200 1
9 • BOLT 3560-13261 1
10 • WASHER 3560-13290 1
11 • PINION T3108-13310 1
12 • BEARING T3300-13530 1
13 • RING T3300-13330 1
14 • SNAP RING 04065-02412 1
15 • FITTING 3199-13350 1
16 • WASHER 01641-20608 1
17 • BOLT 01252-30520 1
18 • HOLDER(A) T3300-13240 1
19 • HOLDER(B) 6019-13250 1
20 • BOLT 01252-30510 1
21 GRIP 3577-32141 1
22 LEVER COMP T3002-12202 1
23 • LEVER 6110-14412 1
24 • CORD(A) T3002-12220 1
25 • CORD(B) T3002-12230 1
26 TUBE T3003-14510 1
27 CABLE COMP 1855-82100 1
28 PLATE NAME T3108-12511 1
29 PLATE 6425-12552 1
30 HANDLE ASSY 6420-14100 1
31 • HANDLE 6420-14311 1
32 • CLAMP 6420-14320 1
33 • SCREW M5x35 0263-90535 4
34 GUARD ASSY 6357-24001 1
35 • GUARD COMP 6357-24101 1
36 • • GUARD 6041-24113 1
37 • • BLADE 6041-24140 1
38 • • NUT 3320-15310 2
39 • • SCREW 0263-30512 2
40 • CLAMP 3520-24120 1
41 • BOLT 3540-24130 2
42 GOGGLE T3002-91190 1
43 TAP. HEAD COMP PT104 1
44 • CASE COMP 6460-15113 1
45 • COVER 6460-15131 1
46 • CORD HOLDER 6460-15142 1
47 • PLATE 3268-15150 1
48 • SPRING 6041-99162 1
49 • PLATE 3268-15170 1
50 • CORD 6460-15180 1
51 • SPACER 6460-15210 1
52 SHAFT 6041-99240 1
33 
101 9” 22-tooth SST229 1
102 9” 24-tooth SST249 1
103 8” 8-tooth SGB088 1
104 9” 8-tooth SGB089 1
105 8” 4-tooth SGB048 1
106 9” 4-tooth SGB049 1
107 J-HANDLE 6367-14200 1
108 BRACKET 3583-14101 1
109 COVER 6420-13280 1
110 HANGER-ASSY 6420-17300 1
111 • HANGER-COMP 6420-17400 1
112 • • HANGER 9366-17110 1
113 • • CLAMP 9366-17120 1
114 • • SLEEVE 6420-17410 1
115 • SCREW 0263-90525 1
116 STRAP-ASSY T3002-17200 1
OPTIONAL BLADE & ACCESSORIES
