RedMax BC225DL - Page 35

Key# Description Part Number Q'ty
Fig.2 ENGINE UNIT BC225DL (S/N 000101 and up)
35 
Key# Description Part Number Q'ty
1 CYLINDER 5580-12110 1
2 GASKET, base 5500-12213 1
3 BOLT 1850-12130 2
4 PLUG RCJ-6Y 5602-73110 1
5 CRANKCASE-C 5500-21100 1
6 • PIN 2629-21130 3
7 GASKET 5500-21141 1
8 BEARING 06030-06001 2
9 SEAL 2169-21210 1
10 SEAL 1850-21220 1
11 SNAP RING 04065-02812 1
12 BOLT 01252-30530 3
13 GUARD 5500-22110 1
14 SCREW 0263-90514 1
15 CRANKSHAFT-C 5500-42001 1
16 PISTON 5600-41111 1
17 RING 1100-41210 2
18 PIN 1101-41310 1
19 RING 1260-41320 2
20 BEARING 5500-41410 1
21 WASHER 1101-41340 2
22 MUFFLER ASSY T1702-15100 1
23 ARRESTER 1601-15120 1
24 BOLT 01252-30550 2
25 GASKET T1600-15210 1
26 PLATE 5500-15221 1
27 SCREW 0263-90416 1
28 INSULATOR T1700-13160 1
29 GASKET, insulator 5500-13121 1
30 GASKET, carburetor 5500-13131 1
31 SCREW 0263-90520 2
32 CARBURETOR ASS'Y 5501-81000 1
33 • BODY ASS'Y 1850-81450 1
34 • • SCREEN 3306-81380 1
35 • • VALVE 3356-81310 1
36 • • SPRING 1850-81270 1
37 • • SCREW 1850-81220 1
38 • • PIN 3310-81250 1
39 • • LEVER 3310-81230 1
40 • BODY, purge 1850-81490 1
41 • COVER, pump 1850-81520 1
42 • PUMP, priming 1751-81510 1
43 • DIAPHRAGM 3310-81260 1
44 • GASKET, diaphragm 1850-81470 1
45 • DIAPHRAGM, pump 1065-81420 1
46 • GASKET, pump 1065-81410 1
47 • JET 5500-81251 1
48 • RING 1751-81240 1
49 • RING 1751-81130 1
50 • SWIVEL 1881-81140 1
51 • SCREW 1752-81110 2
52 • BRACKET 5500-81120 1
53 • NUT, adjuster 1751-81180 1
54 • SCREW, adjuster 1918-81170 1
55 • RING 1881-81130 1
56 • SCREW 1850-81530 4
57 • WASHER 5500-81160 1
58 BODY-ASSY T1700-82100 1
59 • BODY 5500-82111 1
60 • SLEEVE 1970-82190 2
61 • PLATE, choke T1700-82130 1
62 • LEVER, choke T1700-82140 1
63 • SCREW 2630-33610 1
64 ELEMENT 5500-82171 1
65 COVER ASS'Y T1701-82200 1
66 • KNOB 5500-82221 1
67 SCREW 0263-90560 2
68 HOUSING-ASS`Y T1702-31100 1
69 • HOUSING T1701-31110 1
70 • BEARING 06002-06001 1
71 • DRUM 4810-31120 1
72 • RING 04064-01210 1
73 • RING 04065-02812 1
74 BRACKET (A) T1700-31212 1
75 BRACKET (B) T1700-31221 1
76 CUSHION T1700-31232 1
77 BOLT 01252-30522 2
78 BOLT 01252-30510 1
79 SCREW 0263-90520 4
80 COVER, engine T1700-32110 1
81 SCREW T1700-32161 1
82 SCREW 0263-90514 1
83 SHOE 1140-51111 2
84 SPRING T1700-51220 1
85 SCREW 1140-51250 2
86 WASHER 1140-51230 2
87 WASHER 1970-51241 2
88 ROTOR T1700-71110 1
89 COIL-A T1700-71200 1
90 • CAP 5500-72110 1
91 • CORD T1700-71220 1
92 • CAP 2616-71320 1
93 • GROMMET 5500-72130 1
94 • SPRING 5500-72120 1
95 BOLT 3310-72150 2
96 SPACER T1700-71260 2
97 CORD-C T1700-73200 1
98 NUT 1650-43230 1
99 KEY 1000-43240 1
100 RECOIL ASS'Y T1700-75100 1
101 • CASE-C 5500-75110 1
102 • REEL 1850-75120 1
103 • SPRING 1850-75130 1
104 • SCREW 1850-75151 1
105 • ROPE T1600-75160 1
106 • KNOB T1600-75310 1
107 • COLLAR T1600-75320 1
108 • SPRING T1600-75330 1
109 • WASHER T1600-75210 1
110 PULLEYASS'Y 1850-75201 1
111 • RATCHET 1850-75221 1
112 • SPRING 1850-75230 1
113 SCREW T1700-32161 4
114 TANK ASS'Y T1700-85001 1
115 • CAP ASS'Y 5607-85201 1
116 • • HOLDER ASS’Y 5601-85300 1
117 • • FILTER 5601-85260 1
118 • • PACKING 5500-85220 1
119 • • STOPPER 4820-85260 1
120 • PIPE-C 5500-85300 1
121 • FILTER ASS'Y 5500-85400 1
122 • CLIP 1260-85460 1
123 SCREW 5910-85510 3
124 CLIP 1950-86120 1
125 LABEL, recoil T1702-75411 1
