RedMax BT225 - Page 29

Key# Description Part Number Q'ty
Fig.1 DRIVE UNIT BT225 (S/N 000001 and up)
Key# Description Part Number Q'ty
1 PIPE COMP. BT01-50810 1
2 DRIVE SHAFT BT01-50710 1
3 HOUSING ASS'Y BT00-50910 1
4 • CASE N/A 1
5 • SHAFT N/A 1
6 • HOLDER N/A 1
7•
SPRING WASHER, M8 BT00-50920 1
8 • WASHER, M8 BT00-50960 1
9 • BEARING 06002-00608 2
10 • BUSHING BT00-50940 1
11 • WASHER M12 BT00-50930 1
12 • BOLT, M5x10 01252-30510 1
13 • BOLT, M5x30 01252-30530 1
14 •
SPRING WASHER, M5 BT00-50950 1
15 • WASHER 01641-20508 1
16 GRIP 3577-32141 1
17 LEVER COMP. T3002-12203 1
18 • LEVER ASS'Y 6110-14412 1
19 • • COVER 6110-14410-02 1
20 • CORD(A), black T3002-12220 1
21 • CORD(B), red T3002-12230 1
22
THROTTLE CABLE ASS'Y 1855-82100 1
23 TUBE T3003-14510 1
24 HANDLE ASS'Y 6420-14100 1
25 • HANDLE 6420-14311 1
26 • CLAMP 6420-14320 1
27 • SCREW 0263-90535 4
28 GUARD ASS'Y BT00-80810 1
29 •
GUARD MOUNTING ASS'Y BT00-80840 1
30 • BLADE ASS'Y BT00-80830 1
31 END CAP, TUBE BT00-50820 1
32 PLATE, name BT01-99010 1
33 PLATE, caution 6425-12552 1
34 TAP HEAD UBT100R 1
35 HOUSING UBT-341R 1
36 EYELET UBT-9 2
37 BOLT
UBTR-F10RHF 1
38 SPRING UBT-354 1
39 SPOOL UBT-345R 1
40 BUTTON UBT-347 1
41 COVER UBT-348L 1
❲ 29 ❳
