RedMax CHT2200 - Page 23

Fig.1 CUTTER GROUP — HT2200
 23 
Parts List
Key# Description Part Number Q'ty Note
1 Gear case T4001-31110 1
2 Cover T4001-31210 1
3 Gasket T4001-31220 1
4 Drum 3884-11410 1
5 Bearing 06004-06001 2
6 Snap ring T4001-31320 1
7Pinion T4001-31330 1
8 Bearing T4001-31340 2
9 Gear comp. T4001-31350 1
10 Rod T4001-31510 2
11 Snap ring 04064-02512 1
12 Fitting 3199-13350 1
13 Felt T4001-31360 1
14 Bolt T4001-31370 6 M5x12
15 Guide plate T4001-32110 1
16 Upper blade T4001-32210 1
17 Lower blade T4001-32220 1
18 Screw(L:19) 3884-11750 3
19 Screw(L:29) 6095-11810 1
20 Washer 3880-11780 4
21 Nut 3880-11790 4
22 Screw T4001-32310 2 M5x16
23 Nut T4001-32320 2
24 Cover, blade T4001-32910 1
25 Handle comp. 6844-12100 1
26 • Grip 3880-13121 1
27 Washer 3883-12130 1
28 Bolt 3883-12140 1 M6x18
29 Handle comp. T4001-34100 1
30 • Grip 3880-13121 1
31 Switch T4001-74100 1
32 Screw 0263-00525 1
33 Nut 0280-10504 1
34 Tube T4001-74310 1
35 Lever assy 3881-13210 1
36 Bolt 0212-50525 2
37 Plate 6095-13310 1
38 Nut 3876-14470 2
39 Band 3880-13350 1
40 Bolt 0225-10614 3
41 Tool set 1111-91003 1
42 • Spanner 3540-91120 1
43 • Socket 1110-91320 1
44 • Driver 1030-91340 1
101 Receive plate 3885-91110 1 OP
102 Wrench 3880-95020 1 OP
103 Wrench 3880-95010 1 OP
Key# Description Part Number Q'ty Note
