Fig.3 CUTTER GROUP — CHT2200
 27 
Parts List
Key# Description Part Number Q'ty Note
1 Gear case T4002-31110 1
2 Cover T4002-31210 1
3 Gasket T4002-31220 1
4 Drum 3884-11410 1
5 Bearing 06004-06001 2
6 Snap ring T4001-31320 1
7Pinion T4001-31330 1
8 Bearing T4001-31340 2
9 Gear comp. T4001-31350 1
10 Rod T4001-31510 2
11 Snap ring 04064-02512 1
12 Fitting 3199-13350 1
13 Felt T4001-31360 1
14 Bolt T4001-31370 7 M5x12
15 Guide plate T4002-32110 1
16 Blade T4002-32210 2
17 Screw (L:19) 3884-11750 4
18 Washer 3880-11780 4
19 Nut 3880-11790 4
20 Screw T4001-32310 2 M5x16
21 Nut T4001-32320 2
22 Cover, blade T4002-32910 1
23 Handle (Front) T4002-33110 1
24 Bolt 0225-30635 2
25 Nut 0280-10605 2
26 Handle (Rear) Assy 6845-13100 1
27 • Switch 6845-13130 1
28 • Pin 3873-13140 1
29 • Spring 3873-13150 1
30 • Cap 3873-13160 1
31 • Plate 3873-13170 1
32 • Screw 3873-13180 1
33 • Wire end 3873-13210 1
34 • Lever 3873-13221 1
35 • Snap ring 3873-13230 1
36 • Stopper 6845-13310 1
37 • Spring 6845-13320 1
38 • Screw 3873-13240 5
39 • Screw 3873-13250 1
40 • Nut 0280-10403 6
41 Bolt 0225-50650 1
42 Nut 0280-10605 1
43 Bolt 0225-50640 1
44 Bolt 0225-10614 2
45 Tool set 1111-91003 1
46 Spanner 3540-91120 1
47 Socket 1110-91320 1
48 Driver 1030-91340 1
101 Wrench 3880-95020 1 OP
102 Wrench 3880-95010 1 OP
Key# Description Part Number Q'ty Note
