RedMax CHT2250 - Page 59

P/L-5
CHT2250
Fig.2 ENGINE GROUP CHT2250
12. Parts list
Key# Part Number Description Q'ty Note
1 5602-12110 Cylinder 1
2 5500-12213 Gasket, base 1
3 1850-12130 Bolt, M5x22 2
4 5500-13163 Insulator 1
5 5500-13122 Gasket, insulator 1
6 5500-13131 Gasket, carb 1
7 0263-90520 Screw, M5x20 2
8 5603-15100 Muffler assy 1
9 5603-15110 • Muffler 1
10 1601-15120 • Spark arrester 1
11 01252-30550 Bolt, M5x50 2
12 5600-15210 Gasket, muffler 1
13 5600-15220 Plate, muffler 1
14 0263-90416 Screw, M4x16 1
15 5600-21100 Crancase comp. 1
16 5500-21141 Gasket, case 1
17 T1802-21240 Bearing 2
18 2169-21210 Oil seal 1
19 1850-21220 Oil seal 1
20 04065-02812 Snap ring 1
21 01252-30530 Bolt, M5x30 4
22 5500-22110 Guard 1
23 0263-90514 Screw, M5x14 1
24 5600-41111 Piston 1
25 1100-41210 Ring, piston 2
26 1101-41310 Pin, piston 1
27 1260-41320 Snap ring 2
28 5500-41410 Bearing 1
29 1101-41340 Washer 2
30 5600-42001 Crankshaft comp. 1
31 1650-43230 Nut 1
32 1000-43240 Key 1
33 1140-51111 Shoe 2
34 1140-51250 Screw 2
35 1600-51223 Spring 1
36 1140-51230 Washer 2
37 1970-51241 Washer 2
38 5600-52110 Case, clutch 1
39 0263-90516 Screw, M5x16 4
40 5600-52150 Plate, clutch 1
41 1650-43230 Nut 1
42 5601-71110 Rotor 1
43 5600-71200 Coil assy 1
44 5600-71220 • Cord 1
45 2616-71320 • Cap 1
46 5500-72110 Cap, spark plug 1
47 1900-72120 Spring 1
48 5500-72130 Grommet 1
49 1260-71261 Spacer 2
50 3310-72150 Bolt, M4x25 2
51 5990-75102 Recoil assy 1
52 5990-75110 • Case, recoil 1
53 5990-75120 • Spring, Spiral 1
54 5990-75131 • Reel 1
55 5990-75141 • Ratchet 1
56 5990-75151 • Spring 1
57 5990-75270 • Screw 1
58 5990-75160 • Retainer 1
59 5990-75170 • Washer 1
60 1861-75180 • Rope 1
Key# Part Number Description Q'ty Note
61 1490-75181 • Knob 1
62 0263-90412 Screw 4
63 5628-83221 Bracket 1
64 5500-13131 Gasket, carburetor 1
65 5602-81001 Carburetor assy, WYL-55 1
66 5850-81110 • Screw 2
67 1751-81130 • Ring 1
68 1881-81140 • Swivel 1
69 – • Valve assy 1
70 1751-81240 • O-ring 1
71 5628-81250 • Jet #37 1
72 5602-06030 • Rebuilt Kit 1
73 1850-81450 • • Body assy 1
74 – • • • Screen –
75 5602-06020 • • Gasket Kit 1
76 – • • • Diaphragm, pump –
77 – • • • Gasket, pump –
78 – • • • Diaphragm –
79 – • • • Gasket, diaphragm –
80 1850-81490 • Body, purge 1
81 1751-81510 • Pump, priming 1
82 1850-81520 • Cover, pump 1
83 1850-81530 • Screw 4
84 5500-85510 Screw 3
85 848-E7T-90C0 Label, recoil 1
86 1601-81810 Cap 1
87 0263-90560 Screw, M5x60 2
88 1950-86120 Clip 1
89 5500-82102 Body assy 1
90 1970-82190 • Sleeve 2
91 5500-82131 • Plate,choke 1
92 5500-82140 • Lever, choke 1
93 2630-33610 • Screw 1
94 5500-82171 Element 1
95 5600-82203 Cover assy 1
96 5500-82221 • Knob 1
97 5600-31110 Cover, fan 1
98 0263-90520 Screw, M5x20 4
99 5600-32101 Cover, engine 1
100 1850-32160 Screw, M5x12 1
101 1900-31410 Screw 1
102 3699-90419-10 Spark plug, RCJ6Y 1
103 1852-72121 Grommet 1
104 5601-73200 Cord comp. 1
105 848-8K4-0010 Clamp 1
106 5601-83100 Cable comp. 1
107 848-8K4-0010 Clamp 1
108 848-E7T-8500 Tank assy 1
109 5607-85201 • Cap assy 1
110 5500-85220 • • Packing 1
111 5601-85300 • • Holder 1
112 5601-85260 • • Filter 1
113 4820-85260 • • Stopper 1
114 5500-85300 • Pipe comp. 1
115 5500-85400 • Filter assy 1
116 1260-85460 • Clip 1
117 T1038-91190 Label 1
