43
Key# Part Number Description Q'ty
1 848-D3G-6501 BLADE ASSY 1
2 T4543-11110 • PLATE, upper 1
3 T4543-11120 • PLATE, lower 1
4 848-D3G-65A0 • BLADE, lower 1
5 848-D3G-65B0 • BLADE, upper 1
6 T4521-11311 • SPACER 9
7 T4520-11331 • SCREW 4
8 01252-30520 • BOLT 3
9 848-845-2500 • BOLT 2
10 T4531-11350 • NUT 5
11 T4543-11410 • PLATE 1
12 848-D30-66E1 • BRACKET 1
13 T4543-11230 • COVER 1
16 848-D30-6112 GEARCASE COMP., upper 1
17 06004-06001 • BEARING 2
18 04065-02812 • RING 1
19 848-D30-61B0 • PLATE 1
20 T4543-42320 • BOLT 2
21 848-D30-6121 GEARCASE COMP., botom 1
22 848-D30-61B0 • PLATE 1
23 T4543-42320 • BOLT 2
24 T4543-21220 GASKET 1
25 848-D30-5111 DRUM 1
26 848-D30-62A0 GEAR, drive 1
27 T4543-42210 GEAR, driven 1
28 T4543-42100 ROD ASSY 2
31 3199-13350 FITTING 1
32 T4543-42410 FELT 1
33 848-845-1600 BOLT 6
34 01252-30625 BOLT 3
35 T4503-31101 HANDLE-R COMP. 1
36 848-D3G-32L0 SPACER 4
37 T4503-31220 HOLDER 2
38 T4503-31230 CAP 2
40 T4519-32100 LEVER ASSY 1
41 1638-84130 • LEVER 1
42 1638-84140 • LEVER 1
43 6844-84150 • TOP 1
44 1638-84160 • CLAMP 1
45 T4519-13300 • CABLE COMP. 1
46 1638-84170 • SPRING 1
47 1638-84180 • SPRING 1
48 0263-60620 • SCREW 1
49 1638-84190 • NUT 1
50 0260-60535 • SCREW 1
51 1638-84210 • NUT 1
52 1638-84220 • SCREW 1
Key# Part Number Description Q'ty
53 T4519-32410 PIPE 1
54 T4519-32510 MOUNT 1
55 T4519-32520 PLATE 1
56 0280-10504 NUT 2
57 T4503-31210 ABSORBER 4
58 T4519-32220 COLLAR 2
59 T4503-32230 WASHER 2
60 08034-20414 BAND 1
61 01252-30530 BOLT 2
62 3540-13260 BOLT 2
63 1565-72311 CLAMP 1
64 848-D3S-90F0 LABEL 1
101 848-8U0-0010 TOOL SET 1
102 T4017-91130 • SOCKET 1
103 3540-91120 • SPANNER 1
104 1030-91340 • DRIVER 1
105 09007-00425 • WRENCH 1
106 T3195-91110 BAG 1
1 848-D3H-6501 BLADE ASSY 1
2 848-D3H-66A0 • PLATE, upper 1
3 848-D3H-66B0 • PLATE, lower 1
4 848-D3H-65A0 • BLADE, lower 1
5 848-D3H-65B0 • BLADE, upper 1
6 T4521-11311 • SPACER 12
7 T4520-11331 • SCREW 7
8 01252-30520 • BOLT 3
9 848-845-2500 • BOLT 2
10 T4531-11350 • NUT 8
11 T4543-11410 • PLATE 1
12 848-D30-66E1 • BRACKET 1
13 848-D3H-68A0 • COVER 1
64 848-D3T-90F0 LABEL 1
HTZ2401-L
Fig.1 CUTTING UNIT HTZ2401 (S/N 60100101 and up)
HTZ2401-L (S/N 60100101 and up)
