49
EBZ7100/EBZ7100RH/EBZ7100-CA/EBZ7100RH-CA
Fig.1 BLOWER GROUP (S/N 70800101 and up)
Key# Part Number Description Q'ty
1 848-L5C-55A2 VOLUTE CASE 1
2 848-L5C-55B5 VOLUTE COVER 1
3 T4970-52510 SCREW M5x25 9
4 848-L5C-55C0 ELBOW 1
5 07000-02095 O-RING 1
6 T4960-57030 SCREW M5x70 2
7 3310-53331 NUT 2
8 T4030-31310 COVER INLET 1
9 T4970-52510 SCREW M5x25 3
10 2750-72230 CLAMP 1
11 T4970-51410 SCREW M5x14 1
12 2750-31290 TUBE 1
13 2750-31911 LABEL 1
14 T4012-32610 LABEL, net 1
15 2750-31510 FAN 1
16 848-816-3500 BOLT M6x35 4
17 848-L5C-31A2 ENGINE COVER 1
18 T4970-52510 SCREW M5x25 4
20 848-L5C-3502 FRAME ASSY 1
21 848-L5C-3510 • FRAME COMP. 1
22 3490-21121 • RING 2
23 848-L5C-35C0 PAD 1
24 3495-21320 CLIP 6
25 848-L30-3611 BAND ASSY 2
26 848-L53-3521 NET COMP. 1
27 1480-74710 CLIP 4
28 2750-32510 DAMPER,UPPER 1
29 848-870-5040 WASHER 1
30 848-815-4000 BOLT M5x40 1
31 T4960-51631 SCREW M5x16 (Large Washer) 2
32 2750-32610 DAMPER,LOWER 2
33 2750-32620 NUT M6 2
34a T4012-85101 TANK ASSY 1
34b 848-L63-8500 TANK ASSY (CA only) 1
35 848-L23-8510 • CAP ASSY 1
36 4500-85300 • • HOLDER ASSY 1
37 4500-85220 • • PACKING 1
38 5601-85260 • • FILTER 1
39 848-L23-85N0 • • STOPPER 1
40 T4012-85300 • PIPE COMP. 1
41 3302-85400 • FILTER 1
42 1260-85460 • CLIP 1
43 T4960-51231 SCREW M5x12 (Large Washer) 2
44 1950-86120 CLIP 1
47 848-L65-83A0 BODY, cleaner 1
Key# Part Number Description Q'ty
48 848-L65-8320 COVER ASSY 1
49 T4012-82220 • COVER 1
50 T4970-52510 • SCREW 2
51 848-L53-83J1 • KNOB BOLT 2
53 T4012-82311 ELEMENT 1
54 T4012-82321 ELEMENT 1
55 848-L58-83P2 HOSE 1
56 848-8K4-0000 BAND ø64 2
59 T4950-52030 BOLT M5x20 4
60 T4012-82710 NUT 4
61 848-L65-65A0 HOSE 1
62 848-L58-6511 SWIVEL JOINT 1
63 848-L58-65D0 PIPE, straight 1
64 848-L5C-65E1 PIPE, END 1
65 848-8K4-0020 CLAMP ø96 1
66 848-8K4-0030 CLAMP ø115 1
67 848-8U0-0020 TOOL SET 1
68 3540-91120 • SPANNER 1
69 848-8U1-0020 • SOCKET 1
71 T4012-82280 LABEL 1
72 848-L65-90R0 LABEL 1
73 848-L65-90S0 LABEL 1
74 848-8X5-0770 LABEL, sound 1
