RedMax EBZ7100 - Français; Tables des Matieres 1. Emplacement des Pieces; Fiche Technique; LA SEGURIDAD PRIMERO las Instrucciones que Se Dan en las Advertencias Contenidas en Este Manual y en las Etiquetas de en el Advertencia Marcadas con el Símbolo Soplador, Hacen Referencia a Puntos Críticos que Se Deben Tomar en Consideración para Evitar Posibles Lesiones Físicas Graves Y, por Esta Razón, Le Solicitamos que Lea Detenidamente Dichas Instrucciones y que las Siga Estrictamente. Tenga Presente que las Etiquetas de Advertencia Pueden Desprenderse O Ensuciarse y Tornarse Ilegibles. si Esto Sucediera, Tome Contacto con el Distribuidor del cual Adquirió el Producto y Solicite Nuevas Etiquetas; Luego, Pegue las Etiquetas en Los Puntos Necesarios.

5
1. Emplacement des pieces 1. Situación de las piezas
Français Español
1. Cadre
2. Sangle d' epaule
3. Chapeau de bougie d’allumage
4. Levier des gaz
5. Contacteur d'arrêt (derrière)
6. Grille
7. Levier de starter
8. Filtre à air
9. Carter de volute
10. Etiquette “PRECAUTION”
11. Etiquette “PRECAUTION” (derrière)
12. Coude
13. Réservoir de carburant
14. Lanceur
15. Contacteur d’allumage
16. Capot moteur
17. Coude de l'admission
1. Bastidor
2. Correa para el hombro
3. Casquillo de la bujía
4. Palanca del regulador
5. Interruptor de parada (atrás)
6. Malla
7. Palanca del estrangulador
8. Depurador de aire
9. Caja de espirales
10. Etiqueta “PRECAUCIÓN”
11. Etiqueta “PRECAUCIÓN” (atrás)
12. Codo
13. Depósito de combustible
14. Arrancador de retroceso
15. Interruptor de encendido
16. Cubierta del motor
17. Recipiente de admisión
Français
2. Fiche technique
■ Model EBZ7100/EBZ7100RH/EBZ7100-CA/EBZ7100RH-CA
Dimensions (LxLxH) mm
EBZ7100/EBZ7100-CA ············································································································371x487x495
EBZ7100RH/EBZ7100RH-CA ··································································································371x467x495
Poids à sec kg ····················································································································································10,6
Capacité du réservoir à carburant litres·················································································································2,1
Type de moteur ···························································································Moteur à essence, 2 temps, refroidi à air
Déplacement cc ···················································································································································64,9
Filtre à air ·····················································································································Débit d’air frais à deux étages
Carburateur (diaphragme) à valve ····················································································································Rotatif
Système d’allumage ···················································································································Allumage numérique
Bougie ·································································································································NGK CMR7H (Antibruit)
Echappement ······························································································································Avec pare-étincelles
Régime du moteur tr/min ························································································································2000 à 7050
Consommation de carburant litre/h······················································································································1,65
Volume moyen d’air (avec conduite standard) m
3
/min·························································································16,6
Volume d’air maximum (sans conduite) m
3
/min······································································································23
Vitesse maximum de l’air m/sec ··························································································································91,6
Longévité en nombre d’heures ····························································································································300
Niveau sonore (50 Feet ANSI B175. 2-2000) dB(A)································································································77
Ces spécifications peuvent être modifiées sans préavis.
Español
2. Especificaciohes
■ MODELO EBZ7100/EBZ7100RH/EBZ7100-CA/EBZ7100RH-CA
Dimensiones (largo x ancho x alto) mm (pulg.)
EBZ7100/EBZ7100-CA ················································································371x487x495 (14,6x19,1x19,4)
EBZ7100RH/EBZ7100RH-CA ······································································371x467x495 (14,6x18,4x19,4)
Peso en seco kg (lbs.)·······························································································································10,6 (23,4)
Capacidad del depósito de combustible litros (fl. oz.) ····················································································2,1 (71)
Tipo de motor ··········································································Motor de gasolina de 2 tiempos tipo enfriado por aire
Cilindrada del pistón cm3 (pulg.3)·············································································································64,9 (3,96)
Depurador de aire························································································Sistema de filtro de flujo puro de 2 fases
Carburador (diafragma) tipo válvula ·············································································································Giratorio
Sistema de encendido······················································································································Encendido digital
Bujía ················································································································NGK CMR7H (a prueba de ruidos)
Silenciador······················································································································Equipado con apagachispas
Velocidad de funcionamiento del motor rpm ··························································································2000 a 7050
Consumo de combustible litros (fl. oz/h) ···································································································1,65 (58,2)
Promedio volumen de aire (w/std Pipes) m3/min. (cfm)·············································································16,6 (586)
Máx volumen de aire (w/o Pipes) m3/min. (cfm) ···························································································23 (812)
Máx velocidad del aire m/seg. (mph) ·········································································································91,6 (205)
Período de durabilidad hrs.···································································································································300
Nivel de ruido (50 Feet ANSI B175. 2-2000) dB(A) ·································································································77
Especificaciones sujetas a cambios sin previo aviso.
